COAXIAL CABLE (COPPER CONDUCTOR, COPPER BRAID SHIELD)
Cable Construction
CONDUCTOR: 1.02 mm annealed copper
INSULATION: 4.60 mm foamed PE
1st SHIELD: CU-PET foil
2nd OVERALL SHIELD: Annealed copper braid, 60% coverage
OUTER JACKET: 7.00 mm black PVC with green stripe
IMPEDANCE: 75 ±3 Ohm
CAPACITANCE: 57 pF/m
ATTENUATION:
100 MHz: 6.8 dB/m
200 MHz: 10 dB/m
800 MHz: 19 dB/m
